The Mountain Bike Frame

The cost of a bike frame is proportionate to its material, as well as the treatment that material
has received.

Currently, there are five types of materials used in bikes – high-tensile steel, chromoly steel, aluminum, titanium, and carbon fiber.

Oversized diameters, heat treating, and butting are tubing material treatments that will increase the
cost of a frame as well.

How to Choose the Right Bike Frame

Choosing the right mountain bike frame can greatly improve your biking experience.

Here are some steps to guide you:

  1. Determine the type of riding you’ll do: Mountain biking includes various styles such as cross country, trail riding, all mountain (also known as “enduro”), downhill, and freeride. Each style requires a different type of bike. Understand your style before you choose a bike frame.
  2. Choose the right frame size: Bike frame size is crucial for comfort and performance. This largely depends on your height and inseam measurements. Most manufacturers provide a size chart that you can refer to.
  3. Decide on the frame material: Mountain bike frames are typically made of aluminum, carbon fiber, steel, or titanium. Each material has its own characteristics in terms of strength, weight, durability, and price.
    • Aluminum is light, strong, and affordable, making it the most common choice.
    • Carbon fiber is lighter and absorbs shocks better but is more expensive.
    • Steel is durable and offers a smooth ride, but it’s heavier and less common in mountain bikes.
    • Titanium combines of these materials but is very expensive.
  4. Suspension type: Mountain bikes generally come in three types: rigid (no suspension), hardtail (front suspension), and (front and rear). The right type depends on where you’ll be riding and your personal preferences.
  5. Geometry: The bike’s geometry affects how it handles and fits you. Consider factors such as head tube angle, seat tube angle, top tube length, and chainstay length.
  6. Budget: Finally, determine how much you’re willing to spend. Remember that apart from the frame, you’ll also need to consider the cost of components like the wheels, brakes, drivetrain, and more.

Once you’ve considered all these factors, you should be able to choose a mountain bike frame that suits your needs and preferences.

Seat tube length

The seat tube length is a key measurement in bike geometry.

It is the length of the seat tube, measured from the center of the bottom bracket (where the pedal cranks go through the frame) to the top of the seat tube (where the seat post enters the frame).

Traditionally, bike sizes were determined based on this measurement. However, with modern mountain bike designs, it’s less often used for determining bike fit.

Instead, reach and stack measurements are more commonly used.

Despite this, seat tube length is still important for determining standover height (the height of the bike over your inseam), and for knowing how much seat post can be exposed or how low you can drop your seat.

Always refer to the manufacturer’s sizing chart when choosing a bike size.

Sale
Mongoose Tyax Comp Adult Mountain Bike, 29-Inch Wheels, Tectonic T2 Aluminum Frame, Rigid Hardtail, Hydraulic Disc Brakes, Mens Medium Frame, Orange
  • Hardtail mountain bike for a high-performance ride on rugged trails, 29-inch wheels with a medium frame fit riders 67 to 70 inches tall
  • Lightweight aluminum frame features internal cable routing for a sleek look, 141 mm rear hub spacing creates a more stable and rigid hardtail
  • 100 mm travel fork helps to absorb bumps in the trail
  • 11-speed drivetrain with trigger shifters provides smooth gear changes
  • Hydraulic disc brakes deliver superior all-weather stopping power

Reach of a mountain bike frame

The reach of a mountain bike frame is a measurement that is becoming increasingly important in determining the right bike size.

It’s the horizontal distance from the center of the bottom bracket (the part of the frame where the pedal cranks go through) to the top-center of the head tube (where the handlebars are mounted).

This measurement is critical because it relates to how roomy the bike feels when you’re standing on the pedals, and it affects how much weight you can put on the front wheel.

A longer reach will make a bike feel more stable at high speeds and more comfortable for taller riders or those who prefer a more stretched out position.

A shorter reach makes the bike feel more agile and may be more comfortable for shorter riders or those who prefer a more upright position.

Remember, reach cannot be adjusted, so ensuring the measurement is correct for your body and riding style is crucial when choosing a mountain bike frame.

Stack height

When choosing a mountain bike frame, you should pay attention to the stack height, which is the distance between the head tube and the bottom bracket.

This measurement is important for XC and marathon racers who want to lower their bar height.

Stack height can also help you determine how low to set the handlebars, giving a general idea of how far down your bike should steer.

Many people fixate too much on the head angle when looking at frame geometry, but judging your ride is not a foolproof way.

The stack height is the vertical distance between the bottom bracket and the top of the head tube, considering fork and seat post height.

Stack height is also important for getting the proper height for the handlebars and the stem.

A bike with a low stack may be difficult to use if you’re trying to pedal.

An A-frame with a high stack is more forgiving for beginners, allowing you to adjust the handlebars to a more comfortable height.

Carbon fiber Bike Frames

A carbon fiber bike frame is a high-performance option that provides several benefits over other materials like aluminum, steel, and titanium.

Here’s an overview of its characteristics:

  1. Lightweight: Carbon fiber is lighter than most other materials used for bike frames. This can result in a more efficient ride, particularly for uphill climbs.
  2. Strength and Stiffness: Carbon fiber has a high strength-to-weight ratio. It’s strong and stiff, which means it can be shaped into just about any form and still maintain strength.
  3. Shock Absorption: Carbon fiber offers excellent vibration-damping properties, which can contribute to a smoother ride on rough terrain.
  4. Customizability: Engineers can manipulate carbon fiber to create varying levels of stiffness and compliance in different areas of the frame. This allows for a high degree of performance customization.

Despite its advantages, there are some things to consider with carbon fiber:

  • Price: Carbon fiber frames are generally more expensive than aluminum or steel frames.
  • Durability: While carbon is strong, it can crack or break if impacted hard enough. Therefore, it may not be choice for riders who tend to be harder on their equipment or for extreme styles of mountain biking.

When considering a carbon fiber bike frame, it’s important to weigh these factors against your riding style, budget, and personal preferences.

Aluminum alloy Bike frames

Aluminum alloy bike frames are a popular choice for many cyclists due to their balance of performance, durability, and cost.

Here’s an overview of their characteristics:

  1. Weight: Aluminum frames are generally lighter than steel but slightly heavier than carbon fiber. This makes them a good middle-of-the-road option for those concerned about weight.
  2. Strength: Aluminum is a strong material that can withstand the stress and strain of rough mountain biking trails.
  3. Cost: One of the main advantages of aluminum is its lower cost than carbon fiber and titanium frames. It offers a good balance of performance and affordability.
  4. Rigidity: Aluminum frames are often quite rigid, resulting in a less comfortable ride on rougher terrain than more flexible materials like steel or carbon fiber.
  5. Durability: Aluminum frames are rust-resistant, which can be advantageous in wet or humid climates.

A few considerations with Aluminum frames include:

  • Ride Feel: Some riders find that aluminum frames transmit more trail vibrations than other materials, leading to a harsher ride feel.
  • Fatigue Life: Over time, aluminum can be susceptible to fatigue stress and may not have as long a lifespan as steel or titanium frames.

When choosing an aluminum bike frame, consider your budget, riding style, and personal preferences. While it might not offer the plush ride of carbon fiber or the longevity of steel, it’s a solid, cost-effective choice for many riders.

Hurley Alle-OOP 29er Dual Suspension Mountain Bike (Silver, Medium / 17 Fits 5’6″-6’0″)
  • Durable Twenty Niner Alloy frame for a forgiving ride
  • Alloy front suspension fork with 100mm to smooth out the trail
  • Rear shock to roll over roots and rocks in comfort; Strong yet lightweight 700c alloy double wall wheels
  • Shimano 21-Speed drive train for smooth shifting; Reliable alloy caliper brakes
  • Comes 85% assembled for quick and easy setup. Size Medium / 17 Fits 5’6″-6’0″

Non-butted bike frames

Non-butted bike frames refer to frames that have a uniform thickness throughout the length of their tubing.

In the context of bike frames, the term’ butting’ refers to varying the thickness of the frame’s tubes – thicker at the ends where strength is required and thinner in the middle to save weight.

Non-butted, or ‘straight gauge’ tubes, do not undergo this process and have the same thickness end-to-end.

Here are some characteristics and considerations:

  1. Strength: Due to their uniform thickness, non-butted frames can be stronger than their butted counterparts. They may be a good choice for riders prioritizing durability over weight savings.
  2. Weight: Non-butted frames are typically heavier than butted frames, as more material is used throughout the length of the tube.
  3. Cost: Non-butted frames can be less expensive to manufacture and thus may be found on more budget-friendly bikes.
  4. Ride Feel: Since non-butted frames use more material, they can result in a stiffer ride than butted frames. This might translate to more transmitted vibrations from the trail.

When choosing a non-butted bike frame, it’s essential to consider your riding style, budget, and personal preference.

High tensile steel
This is a very durable alloy that’s found in lower-priced mountain bikes.

It offers a high carbon content, which makes it less stiff than Chromoly steel, so more materials are needed to make it stiff enough for bicycle frames, which will, in turn, make it that much heavier.

Relatively inexpensive to produce, you’ll find the material in trail bikes, city bikes, and even entry-level mountain bikes.

Some bikes come with a Chromoly seat tube, while the rest are high-tensile steel.

Chromoly steel, often referred to as ‘chromo’, is a high-quality type of steel that is commonly used in bike frames.

It’s an alloy that includes chromium and molybdenum, hence the name ‘chromoly’.

Here’s an overview of its characteristics:

  1. Strength: Chromoly steel is stronger and more durable than traditional steel, allowing thinner, lighter tubing to be used in the bike frame.
  2. Ride Quality: Bikes made from chromoly steel are often praised for their ‘smooth’ ride quality. The material’s natural flexibility absorbs some road or trail vibrations, providing comfort to the rider.
  3. Repairability: Steel and chromoly frames can often be repaired more easily than aluminum or carbon frames. This could be a significant advantage if the bike is damaged.
  4. Cost: Chromoly frames are typically more expensive than regular steel frames but are usually less expensive than carbon fiber or titanium frames.
  5. Weight: While chromoly is lighter than traditional steel, it’s still heavier than materials like aluminum or carbon fiber.
  6. Corrosion Resistance: Chromoly offers better corrosion resistance than regular steel but can still rust over time if not properly cared for.

When considering a chromoly steel bike frame, it’s important to weigh these factors against your riding style, budget, and personal preferences.

Aluminum bike frame
For the past 15 years, aluminum has been refined in pretty much the same way as Chromoly.

Various alloys and heat treatment, oversizing, and butting have been developed.

With dual-suspension bikes, aluminum is preferred as it’s the stiffest and most cost-effective.

Aluminum is stiffer than Chromoly, and therefore it will crack before Chromoly.

Of course, this depends on how you ride and how much abuse you give the frame.

The advantage of aluminum is that the frame is light and stiff through oversizing or butting.

Aluminum bike frames are a popular choice among many cyclists due to their balance between weight, strength, and cost.

Here’s a breakdown of their key characteristics:

  1. Weight: Aluminum frames are lighter than steel frames, making them an excellent choice for those who want a more lightweight bike.
  2. Strength: Aluminum is a sturdy material that can handle the rigors of mountain biking. It provides enough strength to withstand tough trails.
  3. Cost-effective: Compared to carbon fiber and titanium frames, aluminum frames are usually more affordable, making them a popular choice for budget-conscious riders.
  4. Corrosion Resistance: Aluminum is resistant to rust, which can be beneficial in damp climates or for those who frequently ride in wet conditions.
  5. Rigidity: Aluminum frames tend to be quite rigid. While this can lead to increased power transfer and handling, it might also result in a rougher ride on bumpy terrain as aluminum doesn’t absorb shocks as well as materials like steel or carbon fiber.

Considerations for Aluminum Frames:

  • Fatigue Life: Over a very long period of heavy use, aluminum can be susceptible to fatigue stress.
  • Ride Feel: Some riders find that aluminum frames transmit more trail vibrations than frames made of carbon fiber or steel, which can result in a harsher ride feel.

When selecting an aluminum bike frame, consider your riding style, budget, and personal preferences.

While it might not offer the ride smoothness of carbon fiber or the longevity of steel, it’s a robust, cost-effective choice suitable for various types of riding.

Titanium Bike Frames

Titanium is a premium material used in bike frames, offering several unique characteristics:

  1. Strength and Weight: Titanium frames are incredibly strong and durable, yet they’re lighter than steel frames. They offer a strength comparable to steel but with a weight closer to aluminum.
  2. Ride Quality: Known for its excellent ride quality, titanium can dampen vibrations, providing a smooth and comfortable ride on various terrains.
  3. Corrosion Resistance: One of the significant benefits of titanium is its corrosion resistance. Unlike steel, it doesn’t rust, making it an excellent choice for riders in wet or humid climates.
  4. Durability and Longevity: Titanium frames are incredibly durable and can last a lifetime if properly cared for.
  5. Repairability: While not as easily repaired as steel, titanium can still be repaired in many cases, which isn’t always true for aluminum or carbon.

However, there are a few considerations when it comes to titanium:

  • Cost: Titanium is one of the most expensive materials used for bike frames. The high cost is due to the raw material cost and the specialized skills and equipment needed to work with titanium.
  • Availability: Titanium frames aren’t as widely available as those made from materials like aluminum or carbon fiber.

When considering a titanium frame, it’s crucial to consider your budget, the type of riding you’ll be doing, and your long-term needs. The initial investment might be higher, but a titanium frame could last you a lifetime.

More compliant than Chromoly, it offers better fatigue and corrosion properties.

The material you choose for your bike depends on where you ride and your style.

Almost all materials will last you for years if you take care of your bike and treat the frame respectfully.
